Volvo L120F Wheel Loader
Wheel Loader // Volvo
Volvo L120F Bucket
| Bucket Capacity - heaped: | 4 cu yds (3 m) |
| Bucket Width: | 9.5 ft (3 m) |
Volvo L120F Dimensions
| Dump Clearance at Max Raise: | 9.2 ft (3 m) |
| Ground Clearance: | 1.4 ft (0 m) |
| Height - Top of Cab: | 11.1 ft (3 m) |
| Hinge Pin - Max Height: | 13.5 ft (4 m) |
| Length with Bucket on Ground: | 27 ft (8 m) |
| Reach at Max Lift and Dump: | 4.4 ft (1 m) |
| Wheelbase: | 10.5 ft (3 m) |
| Width Over Tires: | 8.8 ft (3 m) |
Volvo L120F Engine
| Aspiration: | Turbocharged with Intercooler |
| Displacement: | 433.3 cu in (0 m) |
| Engine Model: | D7ELAE3 |
| Gross Power: | 241.4 hp (180 kw) |
| Net Power: | 240.1 hp (179 kw) |
| Number of Cylinders: | 6.0 |
| Power Measured @: | 1700 rpm |
| Torque Measured @: | 1500 rpm |
Volvo L120F Hydraulic System
| Dump Time: | 2.1 sec |
| Lower Time: | 2.5 sec |
| Pump Flow Capacity: | 38.4 gal/min (145 l/min) |
| Raise Time: | 5.4 sec |
| Relief Valve Setting: | 3630 psi |
Volvo L120F Operating Specifications
| Alternator Supplied Amperage: | 80 A |
| Cooling System Fluid Capacity: | 18.5 gal (70 l) |
| Engine Oil Fluid Capacity: | 5.6 gal (21 l) |
| Front Axle/Diff Fluid Capacity: | 9.6 gal (36 l) |
| Fuel Capacity: | 71.1 gal (269 l) |
| Hydraulic System Fluid Capacity: | 35.2 gal (133 l) |
| Operating Voltage: | 24 V V |
| Operating Weight: | 41843.8 lbs (18,980 kg) |
| Rated Bucket Capacity: | 3.4 - 12.40 cu yds (3 - 9 m) |
| Rear Axle Oscillation: | 13 ° |
| Rear Axle/Diff Fluid Capacity: | 10.9 gal (41 l) |
| Static Tipping Weight: | 32055.3 lbs (14,540 kg) |
| Tire Size: | 23.5R25 |
| Transmission Fluid Capacity: | 21 ft (6 m) |
| Turning Radius: | 10.1 gal (38 l) |
| Max Speed - Forward: | 21 ft (6 m) |
Volvo L120F Transmission
| Max Speed - Reverse: | 23 mph (37 kph) |
| Number of Forward Gears: | 23 mph (37 kph) |
| Number of Reverse Gears: | 4.0 |
| Transmission Type: | 4.0 |
